Single Camera Entity Wields Dominance

In an exciting development for the open-source hardware community, a new camera module testbed has been made available. This innovative device, utilising a first-generation 7'' touchscreen from the Raspberry Pi Foundation, is designed for evaluating various camera modules.

The testbed, initially being tested by [Jenny], can be powered through a wall wart or power bank, making it versatile for different applications. Any Raspberry Pi can be used with this testbed, although the choice of camera module may necessitate a newer version of the Pi.

[Jenny] follows best-practice for open source hardware, making the CAD files openly available for anyone interested in modifying or replicating the testbed. The files, available on GitHub, include proper CAD files in the OpenSCAD format, specifically SCAD files, that can be used for fabrication.

The hardware to be evaluated in this testbed is camera modules. These are mounted on 3D printed front plates and the body with self-tapping screws. The 7'' touchscreen camera enclosure serves as a test mule for camera sensors, providing a practical and cost-effective solution for testing and comparing different camera modules.

If desired, modifications such as adding a battery or a tripod mount can be made using the provided CAD files. The device does not require a battery as it is solely a test mule for camera sensors.

The OpenSCAD file for the 7'' touchscreen camera enclosure was uploaded by the person known as "Prilchen." The files related to the testbed device are all available on GitHub under a CC4.0 license, allowing for free use, sharing, and adaptation of the project.

The tip line is open to everyone, and everyone is welcome to share their own projects. [Jenny List] is credited for providing the tip about the testbed device. These first-gen 7'' touchscreens were nice little screens in the past and still serve well now, making them an ideal choice for this testbed.

In conclusion, the camera module testbed offers an accessible and practical solution for evaluating various camera modules. With the open-source CAD files available, anyone can replicate or modify the testbed to suit their specific needs. The testbed device, coupled with the open-source ethos, encourages collaboration and innovation within the community.
